Insulator：Glass-Filled Thermoplastic PBT BLACK, UL94V-0
Contact：Copper alloy
Shell：Steel, 100u" Tin Over 50u" min Copper
HEX NUT：Copper alloy, Nickel Plated.
L TYPE：Steel, Nickel Plated.
Screwlock：Steel, Nickel Plated.
Electrical
Contact Resistance：20 milliohms Max at 1 AMP DC.
Inslation Resistance：1000 magohms at 500 VDC
Dielectric Withstanding Voltage：1000 VAC/rms 60Hz for 1 minute
Current Rating：5 AMP
Voltage Rating：250 VAC/rms 60Hz
